PARAMETER

参数

VALUE

Rated capacity-R.C. (Emax)

量程

50, 100, 150, 200, 250kg

NTEP/OIML Accuracy class

精度

NTEP

Non-Approved

C3*

C6*

Maximum no,of intervals(n)

分度值

5000 single

1000

3000

6000

Y=Ema*Vmin

10000

1400

6000

10000

Rated output-R.O.

额定输出

2.0 mv/v±0.2%

Zero Balance

零点平衡

±0.2%

Zero return 30 minutes

零点恢复

±0.0330%

±0.0300%

±0.0170%

±0.0083%

Total Error

总误差

±0.0200%

±0.0500%

±0.0200%

±0.0100%

Temp.effect on zero

零点温漂

±0.0023%

±0.0100%

±0.0023%

±0.0014%

Temp.effect on output

灵敏度温漂

±0.0010%

±0.0030%

±0.0010%

±0.00058%

Eccentric loading error

偏心加载误差

±0.0049%

±0.0085%

±0.0049%

±0.0024%

Temperature range

可用温度范围

-10°C to + 40°C

Temperature range, safe

温度补偿范围

-20°C to + 70°C

Maximum safe central overload

安全载荷

150%

Ultimate overload

极限载荷

300%

Excitation, recommended

推荐激励电压

10VDC/AC

Excitation, maximum

最大激励电压

15V DC/AC

Input impedance

输入阻抗

415 ohm±20 ohm

Output impedance

输出阻抗

351 ohm±5 ohm

Insulation resistance

绝缘阻抗

>2000 M ohm

Cable length

线长

1.5 m

Environmental protection

防护等级

IP66

Platform size (max)

支撑台面尺寸

400×400mm
