Rated Output

额定输出

3.0mv/v±0.1%

Zero Balance

零点平衡

±1%

Creep after 30 minutes

蠕变

±0.03%

Nonlinearity

非线性

±0.03%

Hysteresis

滞后

±0.02%

Repeatability

重复性

±0.02%

Temp.effect on output

灵敏度温漂

≤0.002%

Temp.effect on zero

零点温漂

≤0.002%

Safe Temp.Range

可用温度范围

-10°C to + 80°C

Temp.Compensated

温度补偿范围

-10°C to + 50°C

Safe Overload

安全载荷

1.5 X rated capacity

Input Impedance

输入阻抗

775 ohm±5 ohm

Output Impedance

输出阻抗

700 ohm±3 ohm

Insulation Resistance

绝缘阻抗

≥5000 M ohm（50VDC）

Rated Excitation

推荐激励电压

10V DC/AC

Maximum Excitation

最大激励电压

20V DC/AC

Cable Length

导线长度

6.1m

Cable Color Code

导线颜色

Red (+E) Blach(-E) Green(+S) White(-S)
